Product Description
| Model | Sheet Length (mm) |
Steel (mm) |
Stainless (mm) |
Aluminium (mm) |
Axis Speed ( Y°/ Z / X mm ) /sn |
Motor Power ( Y / Z / X ) kW |
Dimensions W / L / H (mm) |
Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| FMB 2030 | 2050 | 3 | 2 | 4 | 65 / 60 / 200 | 3 / 1,5 / 0,4 | 2500/3250/2100 | 3500 |
| FMB 2525 | 2550 | 2,5 | 1,5 | 3,5 | 65 / 60 / 200 | 3 / 1,5 / 0,4 | 2500/3850/2100 | 4350 |
| FMB 3220 | 3200 | 2 | 1,2 | 3 | 65 / 60 / 200 | 3 / 1,5 / 0,4 | 2500/4450/1900 | 4700 |
| FMB 3240 | 3200 | 4 | 2,5 | 6 | 65 / 60 / 200 | 3 / 1,5 / 0,4 | 2500/4750/2100 | 7400 |
| FMB 4215 | 4200 | 1,5 | 1 | 2 | 65 / 60 / 200 | 3 / 1,5 / 0,4 | 2500/5750/2100 | 8900 |
| FMB 4225 | 4200 | 2,5 | 1,5 | 3,5 | 65 / 60 / 200 | 3 / 1,5 / 0,4 | 2500/5750/2100 | 9100 |
Standard Features
- 160 mm stroke capacity and 20° single piece sharp nose tool
- Erfold Basic CNC line by line controller software on 15.4” touchscreen controller
- 1000 mm motorized back gauge system and sheet support table with ball casters
- Manual folding beam adjustment as 80 mm
- 3 swtich control foot pedal
- Front light barriers
- Led function lights
Optional Features
- 1500 / 2000 / 3000 / 4000 mm motorized back gauge system and sheet support table
- L shape back gauge system (metal or with brushes)
- U shape back gauge system (metal or with brushes)
- Motorized folding beam adjustment as 80 mm
- Solid lower beam tool with feather grooves
- Erfold Advanced / 3D CNC graphic control software on touchscreen controller with swivel arm
- Manual crowning system
- 90 mm high segmented goat foot tools
- 60 mm high segmented goat foot tools
